C Frame Robotic System Equipment

18060000.00 INR/Unit

Get a Price/Quote

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

C Frame Robotic System Equipment Price And Quantity

Minimum Order Quantity 1 Unit
Price 18060000.00 INR/Unit

C Frame Robotic System Equipment Trade Information

Supply Ability 50 Unit Per Week
Delivery Time 1-3 Months
Main Domestic Market All India

Product Description

We are renowned as a Manufacturer and Supplier of C Frame Robotic System Equipment (C Frame Spot Welder), based in Vadodara, Gujarat, India. The offered range is designed and developed under the guidance of our team of well-experienced professionals, by using the top-notch quality components and modern techniques. All the products are designed as per the requirement of our precious customers. Furthermore, the range of C Frame Robotic System Equipment (C Frame Spot Welder) is available to us at very reasonable price.

Application of C Frame Robotic System Equipment :

Steam Turbine Blade
Other Details:
Master-slave control, 18-axis sychronized robot welding system
2-axis C-support with two 6-axis robot to achieve maximum working envelop and system flexibility
2-axis robot positioner with payload up to 5,000kg
Hot wire TIG welding process
Visual monitoring system

Seam finding and AVC control
Information :

2-axis C-support with two 6-axis robot to achieve maximum working envelop and system flexibility
2-axis robot positioner with payload up to 5,000kg
Hot wire TIG welding process
Master-slave control, 18-axis sychronized robot welding system
Seam finding and AVC control
Visual monitoring system

Hydrant Turbine Component
Information :

10-axis sychronized robot welding system
3-axis C-support with single-axis arc guide rail and 6-axis robot to achieve maximum working envelop and system flexibility
MIG/MAG welding process
Well-developed software for arc welding of medium/thick plate

Specification :

	Single Shaft	Movable	Rotatable & adjustable
C Frame Height	3418mm	3418mm	3418mm
Arm Center Distance	147z0mm		147z0mm
Rotary Degree	+180o	+180o	315o
Rotary Speed	18o/sec	18o/sec	24o/sec
Repeatability	+ 1.5 arc min	+ 0,2 arc mm	+ 1.5 arc min
