I-ARC401 Orbital Welding Power Source

I-ARC401 Orbital Welding Power Source

1600000.00 INR/Piece

Product Details:

X

I-ARC401 Orbital Welding Power Source Price And Quantity

  • 2 Piece
  • 1600000.00 INR/Piece

I-ARC401 Orbital Welding Power Source Trade Information

  • 50 Piece Per Month
  • 30-45 Days
  • Wooden Packing
  • All India

Product Description

Features of I-Arc401-Power-Source :

  • Windows CE embedded type working system with upgradable easy user interface for hassle free operation.
  • Hundred of programs inside memory storage along with external USB facility for exporting and importing information.
  • There are 20 levels for every single programme for precise regulation as per welding requirement.
  • Genuine-time welding ground record in the course of welding process.
  • Alterable parameter in the course of welding activity for some specific requirements.
  • Integrated many welding head grounds for exact motion regulation.
  • Regulation pendant screen for real-time information supervision.
  • Impeccable error detection solution, fault screen and standard design for simple maintenance.
  • Water chilling set-up to make sure prolonged time of operation.
  • Choices to select offline printing and programming.
  • Hard metal case and elective mobile trolley for easy transportation.

Technical Details:

<!-- BODY,DIV,TABLE,THEAD,TBODY,TFOOT,TR,TH,TD,P { font-family:"Arial"; font-size:x-small } -->

Name iArc401
Type Inverter
Current 5-400A
Duty cycle 400A 60%/310A 100%
Open Circuit Voltage 72V
Input Voltage 3*380V+ 10% 50/60HZ
Power 13.5KVA
Cooling Air cooling
Edit PC
Display Remote controller/Industrial PC/Parameter real-time display in CN & EN
Program Storage 100
Expert parameter Pre-storage
Numbers of Level 20
Torch Cooling External water circuit
Water Tank Type CW-04
Weight 260KG
Manufacture Standard GB15579- 2004
Insulation/Protection Class F / IP23
Dimension 710mm*500mm*1500mm
